POTOK FED360
unit in a one-piece outer enclosure
Induct mount units are integrated into the ventilation system for decontamination and High Efficiency filtration of air. Designed for decontamination and filtration of inlet air in rooms of class I and II; Used for decontamination and filtration of air extracted from the rooms of infectious diseases wards and TB wards. Induct devices are installed as part of the venti­lation ducts as close as possible to the room that needs air decontamination, in a suitable place for installation (above a suspended ceil­ing, in a utility room, etc.). Depending on the need, the device housings are made of painted or stainless steel.
Technical Specifications
Dimensions:
724x574x278 mm
Weight:
23 kg
Power consumption:
10 W
Capacity min:
180 m³
Capacity max:
360 m³
Aerodynamic resistance min:
150 Pa
Aerodynamic resistance max:
350 Pa
Union flanges size:
200 mm
